T1 Plug in Flat-4 |
 |
T1 wiring requires no soldering, splicing or cutting. The electrical connections are
plugged into your factory harness for a factory function and look. If a
tail-light converter or fuse is required it is supplied in the kit.
Electrical Wiring Look Up by Manufacturer
|
Brake Controls |
 |
|
Why Do I Need a
Brake Control?
|
|
Trailers with an combined trailer weight (including the load) over 3000
pounds should be fitted with brakes to comply with provincial road regulations.
Any trailer with electric brakes needs a brake controller to activate the
operation of the brakes. The brake controller sets the timing and level of power
output to the trailer brakes when activated by pressing the brake pedal in the
vehicle. |
|
Brake Control by Manufacturer
|
|
|
|
Standard
Electrical Connector Wiring Diagram |
|
Standard wiring pictured below, viewed from the rear of connector (where
wires attach). Not all trailers/vehicles are wired to this standard. The
use of an
electrical circuit tester is
necessary to ensure proper match of vehicle's wiring to trailer's
wiring.
